Municipal Wastewater Treatment
Characteristics of
Municipal Wastewater
Municipal Wastewater
The quality of municipal wastewater is relatively stable, but the water volume fluctuates greatly. Due to the residential water peak period, it is often in the low load operation mode, and some water quality will have low influent COD and insufficient carbon source. In addition, for projects where rainwater and sewage are not diverted, the water volume affected by weather conditions will increase sharply, and the lack of nutrients in the water will lead to sludge loss.
Most of the park's wastewater is directly discharged by enterprises or reaches the discharge standard after treatment by enterprises. Its quality changes greatly, and the inffluent water volume is greatly affected by the production and drainage cycle of enterprises. In general, there are many refractory substances in the water, the composition is complex, the biodegradability is poor, and the requirements for the impact load resistance of the system are high.
MBR Process Flow Sheet
Process Flow Chart of Wastewater Treatment
An Industrial Park Project in Jiangsu Province
Outline of the Facility：
An industrial park project in Taizhou with a 4800 ³/ D treatment capacity, which was equipped with a total of 20 groups of PE150II-160-3S membrane modules ,had been working since 2021.
Performance：
The influent COD concentration of the biochemical tank is 100-150mg/l, and the ammonia nitrogen is 15-25mg/l. The sludge concentration of the MBR tank is stable at about 6000-8000mg/l. The effluent COD is less than 50mg/l, and the ammonia nitrogen is less than 5mg/l. Cleaning and maintenance are carried out every 3 months with a stable membrane operation.
Performance：
The influent COD concentration of the biochemical tank is 100-150mg/l, and the ammonia nitrogen is 15-25mg/l. The sludge concentration of the MBR tank is stable at about 6000-8000mg/l. The effluent COD is less than 50mg/l, and the ammonia nitrogen is less than 5mg/l. Cleaning and maintenance are carried out every 3 months with a stable membrane operation.
Some Case Studies Offered：
● Taizhou project of 4800m³/d in Jiangsu Province（2021）
● Pingyao project of 2000m³/d in Shanxi Province（2020）
● Foxconn project of 3000m³/d in Guangdong Province（2016）
● University of Finance and Economics project of 5000m³/d in Guangdong Province（2017）
● Weigao project of 2000m³/d in Shandong Province（2018）
● Qiandeng project of 6000m³/d in Jiangsu Province（2020）
● Ningnan project of 5000m³/d in Sichuan Province（2020）
● Peking University project of 2500m³/d in Beijing City（2021）
● Pingyao project of 2000m³/d in Shanxi Province（2020）
● Foxconn project of 3000m³/d in Guangdong Province（2016）
● University of Finance and Economics project of 5000m³/d in Guangdong Province（2017）
● Weigao project of 2000m³/d in Shandong Province（2018）
● Qiandeng project of 6000m³/d in Jiangsu Province（2020）
● Ningnan project of 5000m³/d in Sichuan Province（2020）
● Peking University project of 2500m³/d in Beijing City（2021）
Municipal sewage
In wastewater treatment, PEIER MBR is often a technology of choice over conventional treatment.
In most countries, statutory regulation for discharge and reuse of municipal wastewater are enforced.
Zhengzhou Municipal Government
Angola International Airport Wastewater Treatment
Capacity: 500m³/day
Tianzhou Mountain Scenic Spot in Anhui Province
Capacity: 800m³/day, water reuse for green irrigation.
Zhengzhou Green Expo Park
Capacity: 800m³/day, for water reuse
Shenzhen Foxconn
Capacity: 3000m³/day, for reuse and irrigation purpose
Wastewater Treatment USA
Capacity: 270m³/day, for reuse and irrigation purpose
Australia Portable Camps
Capacity: 30m³/day total in 19 Sets for reuse and irrigation purpose
Kunming Institute of Metallurgy
Capacity: 5000m³/day
Kunming Institute of Metallurgy
Capacity: 5000m³/day
Kunming Institute of Metallurgy
Yixing Rural Domestic Wastewater
Capacity: 60m³/day, directly into the river or green irrigation
Guangxi Longzhou Sanitary Landfill Plant
Capacity: 80m³/day Landfill wastewater treatment
Mining Company Wastewater
Food Process Company Wastewater
Zhengzhou Dennis Shopping Mall
Shangri-La-Hotel Wastewater in China
Water Reuse and Japanese EK Series Replacement Project in Australia
Iraq Clients Visit MBR Package System
Peier is the biggest flat sheet membrane supplier in China.
"Make good products, sell good products and let customers make good use of products" is the business purpose of the company.
